Technical Data:
Depth: 610 mm
Width: 610 mm
Height: 2400 mm
Material: 1.5 mm thick Magnelis
Color: RAL 7035
Weight: 129 kg
Tightness Class: IP 54
Mechanical Protection Class: IK 10
Cabinet Capacity: 19" 42U (two modules: 21U each)
Features:
Two rows of 19" rack holders, adjustable 9cm front/back
Dual 19" modules (21U top and bottom)
Air circulation within the cabinet
Secure locking system with a three-point slide key code and padlock option
Grounding connectors
Options for floor plate installation with rubber bushings for cables
Mounting options for ventilation and heating sets with a thermostat
Potential for thermal and acoustic insulation internally
Application:
This cabinet is tailor-made for telecommunications settings where secure, adaptable, and efficient equipment installation is needed. It's ideal for organizing and protecting the infrastructure necessary for network operation in environments where space optimization and equipment safety are priorities.
