Technical Data:
Material: High-Density Polyethylene (HDPE)
Inner Diameter: 8 mm
Outer Diameter: 10 mm
Pressure Resistance: Minimum 15 bar
Inner Lining: Silicore, with a low coefficient of friction (<0.1)
Optional Features: Anti-Static inner layer
Features:
This product is designed with a co-extruded, permanently lubricated inner layer, Silicore, which provides a lower inner coefficient of friction for maximum cable blowing length. It also features an anti-static inner layer to counteract friction from static electricity build-up. Available in 13 opaque RAL colours or colourless with stripes of 13 opaque colours, it boasts improved impact and compression resistance and is made from high-quality materials for long-life expectancy.
Applications:
The MicroDucts HDPE 10/8 mm is ideal for creating new direct buried pathways or for placing as a subduct in existing lines. It can be installed by pulling, blowing, or pushing in existing duct systems, accommodating single MicroDucts or bundles. It can also be utilized in other DB bundles such as FuturePath HDPE and FuturePath Flex.
