Technical Data:
Amp. Rating: 5.0 A @10°C increase (measured), 7.0 A @20°C increase (calculated)
Transfer Impedance (CoMeT): Class A++, with specific values for different frequency ranges
Screening Attenuation(CoMeT): Class A++, with specific values for different frequency ranges
Return Loss (IEC 61169-1): Better than specified values for different frequency ranges
Insertion Loss Max.: Better than specified values for different frequency ranges
Temperature: Operating range from -40° to +70° C
Features:
Sealing Test: IP X8 30 meter / 8 hours (@ 500 VDC), with high insulation resistance
Dielectric Strength: O-rings EPDM, with a DC Test Voltage of >2.0 KV
Max. Tensile Strength: 102 Kgf for body parts, 1000 N for inner conductor
Torsional Strength: Nitin-6 material used for connector/cable
Applications:
This connector is suitable for applications requiring a wide frequency range and specific impedance, with reliable performance in varying temperatures and high insulation resistance.
