Technical Data:
Part Number: 0132190
Material: HDPE for connector body and caps, ABS/POM for grab rings
Dimensions: Fits 32mm tubes with a tolerance of -0.5 to +0.5mm
Angle: 45° branch tube outlet
Minimum Bend Radius: 25cm for guide tube
Tensile Strength: Withstands forces above 1500 Newtons
Temperature Resistance: Impact-tested at -5°C
Ingress Protection: Tested in mud, sand, and rubble, minimal debris ingress after 24 hours
Design Lifetime: Minimum of 20 years
Features:
Easy alignment and manual tightening without tools
Split caps for easy assembly and long-term performance
Sealing arrangement to protect against mud, sand, and debris
Designed to minimize residual stress for long-term stability
Application:
Ideal for use in access networks, the Y-Connector facilitates the connection of trunk tubes to customer premises, allowing for the smooth blowing or pulling of cables. Suitable for environments exposed to harsh conditions, ensuring reliable performance and durability.
